Product specifications: 1X2X22AWG

Conductor material: 1/0.64Solid annealed copper conductor

Conductor class: acc. to IEC 60228

Core insulation: PEF  OD:2.55mm

Core identification: red, green

shield: Aluminum-plastic compound tape wrapped, tinned copper wire braided shield

Inner sheath: PVC   OD:5.4mm

Outer sheath: PVC   OD:8.0mm

Sheath color: Purple RAL4005

Operating voltage:100V

Conductor resistance: acc. to IEC 60228

Electrical data

Damping per unit length

● 9.6 kHz / Maximum value: 0.0025 dB/m
● 38.4 kHz / Maximum value: 0.004 dB/m
● 4 MHz / Maximum value: 0.022 dB/m
● 16 MHz / Maximum value: 0.042 dB/m

Wave resistance

● rated value: 150 Ω
● 9.6 kHz / 270 Ω
● 38.4 kHz / 185 Ω
● 3 MHz ... 20 MHz / 150 Ω

Relative symmetrical tolerance

● 9.6 kHz / Wave resistance: 10 %
● 38.4 kHz / Wave resistance: 10 %
● 3 MHz ... 20 MHz / Wave resistance: 10 %

Loop resistance per unit length / Maximum value: 110 mΩ/m

Shield resistance per unit length / Maximum value: 9.5 Ω/km

Capacitance per unit length / 1 kHz: 28.5 pF/m

Minimum bending radius fixed: 7.5 x d

Minimum bending radius moved: 15 x d

Temperature range: -40 °C / +80 °C

Flame retardant class: Self-extinguishing, acc. to IEC 60332-1
