02YSY(ST)C11Y(6XV1830-0JH10) Ethernet Connection Cable

02YSY(ST)C11Y(6XV1830-0JH10) Ethernet Connection Cable

6XV1830-0JH10 This cable is used in industrial fieldbus systems in automation and communication technology. It is suitable for chemical and mechanical stress environments and has strong corrosion resistance.
inquiry
  • Product details
Product introduction
  • 01 Product applicationThe cable is used in industrial fieldbus systems in automation and communication technologies. It is suitable for chemical and mechanical stress environments and has strong corrosion resistance.
  • 02 Product characteristics •Oil resistance
    •Waterproof•Corrosion resistance
  • 03 Technical certification Conform to RoHS standard
Structural specification

Product specifications:1X2X22AWG

Conductor material:1/0.64Solid annealed copper conductor

Conductor class: acc. to IEC 60228 standard

Core insulation:PEF  OD:2.55mm

Core iidentification: red and green

Shield:Aluminum - plastic composite tape wrapped, tinned copper wire braided shield

Inner sheath:PVC   OD:5.4mm

Outer sheath:PUR   OD:8.0mm

Jacket color: Purple RAL4005

Operating voltage:80V

Conductor resistance:Conform toIEC 60228 clstandard

Electrical data

Damping per unit length

● 9.6 kHz when / Maximum value   0.0025 dB/m
● 38.4 kHz when / Maximum value    0.004 dB/m
● 4 MHz when / Maximum value      0.022 dB/m
● 16 MHz when / Maximum value     0.042 dB/m

Wave resistance

● rating     150 Ω
● 9.6 kHz when    270 Ω
● 38.4 kHz when    185 Ω
● 3 MHz ... 20 MHz when   150 Ω

Relative symmetric tolerance

● 9.6 kHz The wave resistance of time   10 %
● 38.4 kHz The wave resistance of time  10 %
● 3 MHz ... 20 MHz The wave resistance of time 10 %

Circuit resistance per unit length / Maximum value:110 mΩ/m

Shielding resistance per unit length / Maximum value:9.5 Ω/km

Capacitance per unit length / 1 kHz when   28.5 pF/m

Min. bending radius fixed 7.5 x d

Min. bending radius moved 15 x d

Temperature range :-40 °C / +80 °C

Burning behavior: Self-extinguishing, consistentIEC 60332-1Standard, oil resistance meets IEC 60811-2-1(7X24h/90°C)
