Product introduction
-
01 Product application
For supervisory electrical equipment, station control circuits, outdoor, suitable installation in dry or wet cable trenches.
-
02 Product characteristics
• Flame resistance
-
03 Technical certification •conform to RoHS,
•We are pleased to produce special versions, other dimensions, core and jacket colours on request.
Product structure
Conductor material: Circular or compacted circular stranded annealed copper wires
Seperator: A proper separator may be applied to a conductor
Insulation: Polyethylene (PE)
Core identification: 2 cores- Black and white; 3 cores- Black, white and red; 4 cores- Black, white, red and green; More than 4 cores: Black core with marking numbers
Filling: Non-hygroscopic material(optional)
Binding tape: Polyester (Mylar) tape (optional)
Outer sheath: Polyvinyl chloride (PVC)
Outer sheath color: black RAL9005: gray RAL7001 (optional)
Rated voltage: 600V
Test voltage: 3.5kV
Maximum conductor temperature: 90℃ (normal optional)
Product identification: Aein bei ke® SHANGHAI AEIN WIRE ＆ CABLE CO.,LTD Model number specification voltage Meter mark
