Conductor material: bare copper stranded
Conductor class: according to DIN VDE 0295 Class 6,IEC 60228 cl.6
Core wire insulation :PVC-J-105-003(2105-LF)
Core identification :< 0.5mm ²:5 core and below using color separation, in line with n. DIN 47100, more than 5 core multi-core cable using core color separation, white ink dot distinction; ≥ 0.5mm ²:5 core and below using color separation, including
yellow/green line, in line with n. DIN 47100, more than 5 core multi-core cable using black core wire, white ink numbered distinction (if there are special requirements on demand)
Integral stranding: The stranding pitch of all core layers is very small
Shielding: tinned copper braid, coverage 80%(optional)
Outer sheath :PUR (matte mist surface oil, acid, alkali, corrosion and waterproof)
Jacket color: Orange, RAL 2004 gray, RAL 7001 black, RAL 9005
Rated voltage :25 and above :0.6/1KV; 0.75 to 16:300/500V:0.5 and below 300/300V
Test voltage :3500V; 2000V; 1500V
Conductor resistance: conforming to DIN VDE 0295 CI.6 /IEC 60228 CI.6 at +20 ° C
Insulation resistance: less than 20 GΩ x km at +20° C
Bending radius fixed :4 x d
Bending radius move :7.5 x d
Moving speed: Self-supporting: max. 10 m/s, coasting: max. 5 m/s
Conductor length: Self-supporting/coasting max. 400 m
Acceleration :max. 100 m/s²
Bending cycle :<35 times /Min, life >12 million times
Temperature rating fixed: -40 °C/+90 °C
Temperature rating shift :-30°C/ +90 °C
