Conductor material:
|
Bare copper conductor
|
Conductor class:
|
Acc. to DIN VDE 0295 class 1 or 2 resp. IEC 60228 class 1 or 2
|
Core insulation:
|
PVC
|
Core identification:
|
Acc. to VDE 0293-308
|
Stranding:
|
Cores stranded in layers
|
Inner sheath material:
|
Filler sheath
|
Shield3:
|
Concentric conductor of blank round copper-wires ceander form
|
Outer sheath:
|
PVC
|
Sheath colour:
|
Black
|
Rated voltage:
|
Uo/U: 0,6/1 kV
|
Testing voltage:
|
4 kV
|
Conductor resistance:
|
At +20 °C acc. to DIN VDE 0295 class 1 oder 2 resp. IEC 60228 class 1 or 2
|
Current-carrying-capacity:
|
Acc. to DIN VDE, see Technical Guidelines
|
Min. bending radius fixed:
|
Single core: 15 x d ; multi core: 12 x d
|
Operat. temp. fixed min/max:
|
-40 °C / +70 °C
|
Operat. temp. moved min/max:
|
- 5 °C / +50 °C
|
Temp. at conductor:
|
+ 70 °C in operation; +160 °C in case of short-circuit
|
Burning behavior:
|
Acc. to VDE 0472-804-B and IEC 60332-1
|
Standard:
|
Acc. to DIN VDE 0276-603 and IEC 60502
|
