Conductor
|
Fine-wire stranded conductor in especially bending-resistant version consisting of bare copper wires (according to DIN EN 60228)
|
|
Conductor insulation
|
Mechanically high-quality, especially low-capacitance TPE mixture
|
|
Conductor construction
|
Cores stranded in short pitch length over a centre element for high tensile stresses
|
|
Conductor identification
|
Cores black with white numerals, one core green-yellow.
1.Core: U / L1 / C / L+
2.Core: V / L2
3.Core: W / L3 / D / L-
4. Core: 4 / N
|
|
Inner jacket
|
TPE mixture suited to the requirements in e-chains®
|
|
Overall shield
|
Extremely bending-resistant braiding made of tinned copper wires. Coverage approx. 70% linear, approx. 90% optical.
|
|
Unshielded
|
No
|
|
Outer jacket
|
Low adhesion, especially abrasion resistant and highly bending resistant mixture on the basis of TPE, adapted to suit the requirements in e-chains®
|
|
Jacket color
|
Signal black (similar to RAL 9004)
|
|
CFRIP®
|
Quickly stripping: CFRIP® tear strip at inner jacket
|
