Conductor material:
|
Bare copper strand
|
Conductor class:
|
Acc. to IEC 60228 cl. 5; exception: 0,34 mm², stranded (7 x 0,25 mm)
|
Core insulation:
|
PVC
|
Core identification:
|
Acc. to DIN 47100 different colours
|
Stranding:
|
Stranded in layers
|
Outer sheath:
|
PVC
|
Sheath colour:
|
Grey, RAL 7001
|
Rated voltage:
|
Uo/U: 250 V; peak-voltage on 0,14 mm² 350 V; > 0,14 mm² 500 V
|
Testing voltage:
|
On 0,14 mm² core/core: 1,2 kV; > 0,14 mm²: core/core: 1,5 kV
|
Conductor resistance:
|
Acc. to IEC 60228 cl. 5
|
Insulation resistance:
|
Min. 20 MΩ x km
|
Current-carrying-capacity:
|
Acc. to DIN VDE, see Technical Guidelines
|
Capacity:
|
Ca. 120 nF/km
|
Min. bending radius fixed:
|
Up to 12 mm Ø 5 x d; up to 20 mm Ø 7,5 x d; > 20 mm Ø 10 x d
|
Min. bending radius moved:
|
Up to 12 mm Ø 10 x d; up to 20 mm Ø 15 x d; > 20 mm Ø 20 x d
|
Operat. temp. fixed min/max:
|
-30 °C / +80 °C
|
Operat. temp. moved min/max:
|
-5 °C / +70 °C
|
Burning behavior:
|
Self-extinguishing & flame-retardant acc.to IEC 60332-1
|
Standard:
|
Similar to VDE 0812
|
