Conductor material:
|
Bare copper strand
|
Conductor class:
|
Acc. to DIN VDE 0295 class 5 resp. IEC 60228 cl. 5
|
Core insulation:
|
Based on polyester
|
Core identification:
|
Acc. to VDE 0293-308 up to 5 wires coloured, from 6 wires white with black numerals with GNYE
|
Stranding:
|
Cores stranded in layers
|
Inner sheath material:
|
Polyurethane
|
Outer sheath:
|
Polyurethane
|
Sheath colour:
|
Black
|
Rated voltage:
|
0,6/1 kV
|
Testing voltage:
|
2,5 kV
|
Current-carrying-capacity:
|
Acc. to DIN VDE, see Technical Guideline, basic table, column D
|
Min. bending radius fixed:
|
6 x d
|
Min. bending radius moved:
|
6 x d (7,5 x d at roller reversing)
|
Operat. temp. fixed min/max:
|
-50 °C / +90 °C
|
Operat. temp. moved min/max:
|
-40 °C / +90 °C
|
Temp. at conductor:
|
+90 °C
|
Burning behavior:
|
Similar to IEC 60332-1
|
Resistant to oil:
|
Acc. to EN 60811-404
|
Torsion:
|
+/- 50 °/m
|
Tensile strength:
|
Without supporting element max. 25 N / mm²
|
