Conductor material: bare copper
Conductor class: According to DIN VDE 0295 Class 6 conductor or IEC 60228 Class 6 conductor
Core wire insulation :PVC-J-105-003(2105-LF)
Core line identification :<0,5 mm²:5 core and below using color separation, IN line with n.DIN 47100, more than 5 core multi-core cable using core line color separation, white ink dot distinction; ≥ 0.5mm²: Color separation is adopted for 5 cores and
below, including yellow/green wire, in line with n.DIN 47100, black core wire is adopted for multi-core cables with more than 5 cores, white ink numbering is differentiated (customized according to special requirements)
Power cable: Black sheath white print U/L1:V/L2:W/L3; GN/PE
Cabling: Each two wire cores are twisted with a short pitch, and then all twisted wires are twisted together around the line with a short pitch
Inner sheath :DQPVC-H-90-003(9039-LF) (PVC filler)
Shielding: tinned copper wire braid shielding shielding density ≥80%
Outer sheath :DQPVC-H-90-003(9039-LF) Low wear, anti-cutting, low adhesion
Jacket color: black (RAL 9005); Grey (RAL 7001): orange (RAL 2004); Green (RAL 6018)
Rated voltage :25 and above :0.6/1KV; 0.75 to 16:300/500V:0.5 and below 300/300V
Test voltage :3500V; 2000V; 1500V
Conductor resistance :+20 "C conforms to DIN VDE 0295 Class 6 conductors or IEC 60228 Class 6 conductors
Small bending radius fixed :4 x d
Small bending radius movement :7.5 x d
Moving speed: Self-supporting: max.8 m/s, coasting: max.5 m/s
Conductor length: Self-supporting/coasting max.400 m
Acceleration :max.100 m/s²
Bending cycle :<35 times /Min, life >8 million times
Operating temperature fixed minimum/maximum :-30°C/+100°C(UL: 90°C)
Operating temperature shift minimum/maximum :-30°C/+100°C(UL: 90 °C)
Flame retardant rating: According to IEC 60332-1-2:UL/CUI FT1, FT2
Certification :CE:UL/CUL If UL certification is required, please specify it separately
Printed identification Aein bei Ke SHANGHAL AEIN WIRE & CABLE CO,LTD Model Specification Voltage FLEXIBLE CONNECTION OIL RESISTANT ABRASION RESISTANT CE Label of drag chain Meter scale
