Conductor material: bare copper
Conductor class: According to DIN VDE 0295 Class 6 conductors or. IEC 60228 Class 6 conductors
Core wire insulation :PVC-J-70-001(7088B)
Core line identification :<0.5 mm²:5 core and below using color separation, IN line with n.DIN 47100, more than 5 core multi-core cable using core line color separation, white ink dot distinction; ≥ 0.5mm ²: Color separation is adopted for 5 cores
and below, including yellow/green wire, in line with n.DIN 47100, black core wire is adopted for multi-core cables with more than 5 cores, white ink numbering is differentiated (customized according to special requirements)
Power cable: Black sheath white print U/L1; V/L2; W/L3; GN/PE
Cable forming: Cores <10: cores are twisted in layers with short pitch; Core wires ≥11: The core wires are twisted twice
Inner sheath :PVC filling material
Shielding: Copper wire braided shielding shielding density ≥80%
Outer sheath :DQPVC-H-70-002(B-70A)
Jacket color: black (RAL 9005), grey (RAL 7001), orange (RAL 2004), green (RAL 6018)
Rated voltage :25 and above :0.6/1KV, 0.75 to 16:300/500V:0.5 and below 300/300V
Test voltage :3500V, 2000V, 1500V
Conductor resistance :+20 °C according to DIN VDE 0295 Class 6 conductors or IEC 60228 Class 6 conductors.
Small bending radius constant :4 x d
Small bending radius movement :7.5 x d
Moving speed: Self-supporting: max, 1.5m /s, coasting: max. 1m /s
Conductor length: Self-supporting/coasting max.400 m
Acceleration :max.100 m/s²
Bending cycle :<20 times /Min, life >5 million times
Flame retardant rating: according to IEC 60332-1-2
Certification :CE
Print identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO,LTD Model Specification Voltage FLEXIBLE CONNECTION OIL RESISTANT ABRASION RESISTANT CE Towing chain mark meter mark
