Product introduction
-
01 Product application Multi-core PVC insulation,PUR Sheath low pressure line used in automobiles, it has excellent wear resistance and better bending resistance.
-
02 Product characteristics • Flame retardant
-
03 Technical certification • Conform to RoHS standard
• Conform to 2014/35/EU-Guideline(" Low voltage directive ")CE
Product structure
Conductor material: Bare copper conductor acc. to DIN EN 13602 standard
Conductor class:ISO 6722 Class B
Core insulation:PVC
Ground conductor material: Tinned copper drainage wire
Shield :Polyester tape with aluminum foil shield wrapped shield
Outer sheath:PUR
Core identification: Color acc. to DIN 47002 and DIN IEC 304 standard
Operat. temp. min/max: --40°C to +105°C
Burning behavor: Self - extinguishing and flame retardant IEC60332-1-2 standard
Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.,LTD Model number specification voltage CE
Product parameter
