Product introduction
-
01 Product application As flexible power and control cables, they are used for high electrical and light to moderate mechanical requirements in towing chains and motion drive systems in mechanical and equipment engineering.
-
02 Product characteristics •Flame retardant coincidence IEC 60332-1-2
•Have 600 V UL/CUL Certification, allowed with other 600 V The cables are laid in parallel
-
03 Technical certification •Conform to RoHS standard
•Conform to 2014/35/EU-Guideline (''Low voltage Directive'') CE
•We are pleased to produce special versions, other dimensions, core and jacket colours on request.
Product structure
Conductor material: bare copper wire
Conductor class: acc. to DIN VDE 0295 5Conductor like or. IEC 60228 5Conductor like
Insulation:PVC
Core label: acc. to DIN VDE 0293 Black with white numbering and yellow/green
Stranding: The core strands are twisted in layers
Outer sheath:PVC
Jacket color: Gray RAL 7001
Rated voltage:H03V2V2-F: 300/300 V H05V2V2-F: 300/500 V H07V2V2-F: 450/750 V
Test voltage:H03V2V2-F: 1 KV H05V2V2-F: 2 kV H07V2V2-F: 2.5 kV
Conductor resistance:+20 °C Conform to DIN VDE 0295 cl. 5 or. IEC 60228 cl.5
Insulation resistance:+20 °C ≥ 20 MΩ x km
Minimum bending radius fixd 7.5 x d
Minimum bend radius moved 15 x d
Operat. temp. fixed min/max:-15 °C / +90 °C
Operat. temp. moved min/max:-5 °C / +90 °C
Burning behavior: Flame retardant class compliance. IEC 60332-1-2
Product identification:Aein bei ke SHANGHAI AEIN WIRE ＆ CABLE CO.,LTD Model number specification voltage CE Meter scale
