Conductor material: bare copper wire
Conductor class: acc. to IEC 60228 cl. 5 standard
Insulation:T18 Type B thermoplastic mixture
Core identification: acc. toDIN VDE 0293Standard, black core, white number,G = withGNYE
Stranding: Stranded in layers
Outer sheath:EM8Type B crosslinking mixture
Jacket color: Gray RAL 7001
Rated voltage:Uo/U: H05ZZ-F 300/500 V; H07ZZ-F 450/750
Test voltage:H05ZZ-F 2KV; H07ZZ-F 2.5KV
Conductor resistance: acc. to IEC 60228 cl. 5standard
Insulation resistance: minimum20 MΩ x km
Min. bending radius fixed:4 x d
Min. bending radius moved:15 x d
Operat. temp. fixed min/max:-40 °C / +90 °C
Operat. temp. moved min/maxOperat. temp. moved min/max:-5 °C / +90 °C
halogen-free:No halogen, yesIEC 60754-1standard
Smoke density:Conform toIEC 61034-1andIEC 61034-2standard
Degree of corrosion:Conform toIEC 60754-2standard
Burning behavior:Halogen-free and flame retardant, conformingIEC 60332-1-2 standard:Be similar to EN 50525-3-11
Product identification:Aein bei ke SHANGHAI AEIN WIRE ＆ CABLE CO.,LTD Model number specification voltage CE
