Product introduction
-
01 Product application
Data transmission cables, control and connection cables, mainly used for connection cables between servo controllers and encoder resolvers. Suitable for demanding towing chains and mobile drive systems. Internal wiring or external interconnection of electronic
equipment, with oil resistance, wear resistance, acid and alkali resistance, water resistance, UV resistance.
-
02 Product characteristics
· Uv radiation
· Flame retardant in line with FT2
-
Technical certification03
· UV resistance
· Flame retardant in line with FT2
· Flame retardant according to UL(Cable flame retardant) standard and DIN EN 60332-1-2(60 seconds)
· Oil resistance, according to DIN EN
60811-404 (168 hours 100°C)
Product structure
Conductor material: bare copper or tinned
Conductor class: According to UL758 standard, STM B3 or ASTM B33 standard, DIN VDE 0295 Class 5 conductor or IEC 60228 Class 5 conductors
Core wire insulation :TPE-E
Core wire identification :<20AWG: 5 core and below using color separation, IN line with n.DIN 47100, more than 5 core multi-core cables using core wire color separation, white ink dot distinction; ≥20AWG: 5 core and below using color separation, including
yellow/green wire, in line with n.DIN 47100,5 core and more multi-core cables using black core wire, white ink numbered distinction (if there are special requirements on demand)
Stranding: stranding in layers
Outer sheath :TPU
Outer jacket color: gray RAL7001
Rated voltage :30V
Test voltage :1500V
Conductor resistance :UL1581 ASTM Class C
Small bending radius fixed :7.5x d
Small bending radius movement :15x d
Operating temperature fixed minimum/maximum value :-40°C/+80°C
Temperature class shift small/large value: -25°C/+80°C;
Flame retardant grade: self-extinguishing and flame retardant meet; CSA C22.2 No.2556-15 FT2
Oil resistance: UL1581:IRM 902; In accordance with DIN EN 60811-2-1
Certification :EAC
