Conductor material: bare copper wire

Conductor class: In accordance with IEC 60228 cl. 5standard

Insulation:HDPE,XLPE(Optional)

Identification of core wire: < 0,5 mm²:5Core and below the use of color separation, in line withn. DIN 47100.5Multi-core cable above core adopts core separation , white ink dot distinguish; ≥ 0,5 mm²: 5Core and below use color separation, containing yellow/Green line, matchn. DIN 47100.5Multi-core cable above the core adopts black core wire, white ink numbered to distinguish(If there are special requirements to customize)

Hinge: 2The core wire is twisted into a pair; Layering of pairs

Shield: tinned copper braid, coverage rate is about 70%.

Outer sheath: special halogen-free compound

Jacket color: Gray RAL 7001;blackRAL9005;

Rated voltage:0.5And below300/300V;0.5above300/500V

Test voltage:0.5 above 300/500V0.5 And below 1500V;0.5 above 2000V

Conductor resistance: In accordance with IEC 60228 cl. 5standard

Insulation resistance: minimum 200 MΩ x km

Capacitor: core/core about 120 nF/km; core/Masking contract 160 nF/km

Minimum bending radius fixed:20 mm The following Ø 7,5 x d, > 20 mm The following Ø 10 x d

Minimum bending radius moved:20 mm The following Ø 15 x d, > 20 mm The following Ø 20 x d

Operat. temp. fixed min/max:-40 °C / +90 °C ; -40 °C / +125 °C

Operat. temp. moved min/max:-5 °C / +90 °C ; -5 °C / +125 °C

Halogen-free:No halogen, In accordance with IEC 60754-2standard

Smoke density: IEC 61034-2standard

Burning behavior:Halogen-free and flame retardant, conformingIEC 60332-1-2standard

Standard:reference DIN VDE 0812

Product identification:Aein bei ke   SHANGHAI  AEIN  WIRE ＆ CABLE  CO.,LTD   Model number  specification voltage   CE
