Conductor material: bare copper wire

Conductor class: acc. to IEC 60228 cl. 5 standard

Insulation: SR PVC-J-80-001

Core identification :< 0,5 mm²: 5 cores and below are distinguished by color separation, acc. to Din 47100, multi-core cables above 5 cores are distinguished by core wire color separation, and white ink is used for distinction; ≥ 0,5 mm²: 5 cores and below are distinguished by color separation, including yellow/ Green ground wire, acc.to Din 47100, multi-core cables with more than 5 cores use black core wires, and white ink numbers are used to distinguish them. (customized upon request if there are special requirements)

Stranding: stranded in layers and back twisted

Outer sheath: PVC-H-70-001

Sheath color: Black RAL9005; grey RAL 7001

Stranding: stranded in layers

Rated voltage: < 0.5: 300/300V; ≥0.5: 300/500V

Testing voltage:< 0.5: 1500V; ≥0.5: 2000V

Conductor resistance: acc. to IEC 60228 cl. 5 standard

Insulation resistance: minimum20 MΩ x km

Capacitance: ca. 120 nF/km

Minimum bending radius Fixed: up to 12 mm Ø: 5 x d; up to 20 mm Ø: 7,5 x d; > 20 mm Ø: 10 x d

Minimum bending radius Moved: up to 12 mm Ø: 10 x d; up to 20 mm Ø: 15 x d; > 20 mm Ø: 20 x d

Operat. temp. fixed min/max: -15 °C / +80 °C

Operat. temp. moved min/max:-5 °C / +80 °C

Conductor temperature: In operation +80 °C; Short circuit +150 °C

Standard: DIN VDE 0812

Product identification: Aein bei ke   SHANGHAI  AEIN  WIRE ＆ CABLE  CO.,LTD   Model number  specification voltage   CE   Meter scale
