Product introduction
-
01 Product application
FEP CE certified silicone rubber cable is suitable for places with extreme temperatures, and it is stable to grease, acid, alkali and solvent. In addition, the FEP insulated core wire is light and has good weather resistance, and can be used all day.
-
02 Product characteristics
High temperature resistance of 260℃
No flame conduction during fire, complete insulation and low smoke density.
Silica gel is resistant to ozone, oxygen, seawater and weather.
Hydrolysis resistance and ultraviolet resistance
When the temperature is above+100℃ and there is no air, the mechanical properties of silica gel wires will be reduced in advance, so adequate ventilation should be ensured.
-
03 Technical certification ·RoHS Compliant
·Complies with 2014/35/EU-Guidelines ("Low Voltage Directive") CE.
• We are pleased to produce special versions, other dimensions, core and jacket colours on request.
Product structure
Conductor: DIN VDE 0295 standard class 5 soft stranded tinned copper conductor.
Conductor resistance: in accordance with IEC 60228 standard
Insulation: FEP insulation
Core identification: Colorful cores according to DIN VDE 0293-308.
Rated voltage: Uo/U: 600 V
Test voltage: 2500V
Minimum fixed bending radius: 15 x d
Temperature class Fixed: -100°C / +200°C
Burning behaviour: IEC 60332-1-2
Standard: VDE 0250 Part 812
Marking: Aein bei ke SHANGHAI AEIN WIRE ＆ CABLE CO.,LTD Model Specification Voltage CE Meter Mark
