Conductor material: Bare copper or tinned copper

Conductor class: acc. to UL758 standard,ASTM B3 or ASTM B33 standard,DIN VDE 0295 Conductor 5 pt.4 or. IEC 60228 Conductor 5 pt.4

Core insulation:PVC(automobile materials)

Core identification:< 20AWG 5 cores and below are distinguished by color separation, acc. to Din 47100, multi core cables above 5 cores are distinguished by core wire color separation, and white ink is used for distinction; ≥18AWG: 5 cores and below are distinguished by color separation, including yellow/ Green ground wire, acc.to Din 47100, multi-core cables with more than 5 cores use black core wires, and white ink numbers are used to distinguish them. (customized upon request if there are special requirements)

Stranding :Layered stranding,Parallel structure

Shield:Tinned copper braid; Coverage is about70%.

Outer sheath:PVC(-40Sheath)

Sheath color: gray RAL7001 or black RAL9005

Rated voltage:300V

Test voltage: core/core:2.0 kV

Conductor resistance:UL1581 ASTM class C

Insulation resistance:+20 °C ≥ 20 MΩ x km

Minimum bending radius fixed:7.5x d

Minimum bending radius flexible:15x d

Operat. temp. fixed min/max:-40 °C / +105 °C

Operat. temp. moved min/max:-30 °C / +105 °C

Burning behavor: Self - extinguishing and flame retardant UL1581VW-1;CSA C22.2 No.2556-15 FT1,FT2;IEC 60332-1-2 standard

Approvals:UL&CUL:UL1569,UL2517
                    CE:FLRYCY  If needed CE certification requirements should be specified separately

Product identification:Aein bei ke E503807  ® AWM  Model number  specification temperature  voltage c®   AWM Ⅰ/Ⅱ A/B specification temperature  voltage  FT2  SHANGHAI  AEIN    Model number  specification voltage CE Meter scale
