Conductor material: copper stranded wire

Conductor class: class 5 acc. to DIN VDE 0295, class 5 acc. to IEC 60228

Core insulation: EP

Core identification: ≤5 cores: black, white, red, yellow green (green), orange   above 5 cores: black RAL9005 cable, with white numbers,  yellow or green cables can be choose

Stranding: Core stranded, fillers

Outer sheath: CPE

Jacket color: black RAL9005 (optional)

Rated voltage: 600V

Testing voltage: ≤13AWG 2000V, 12AWG-9AWG  3000V, 8AWG-2AWG  4000V

Minimum bending radius fixed: 7.5 x d

Minimum bending radius moved: 10 x d

Operat. temp. fixed min/max: -40 °C / +105 °C  -40 °C / +90 °C  -40 °C / +75 °C  -40 °C / +60 °C

Operat. temp. moved min/max: -40 °C / +105 °C  -40 °C / +90 °C  -40 °C / +75 °C  -40 °C / +60 °C

Burning behavior: self-extinguishing, flame-retardant conform to IEC60332-1-2  FT1  VW-1

Oil resistance: acc. to EN 60811-2-1

Certification:  CE: H07RN-F,H07BN4-F,H07RN8-F      If you need CE certification, please indicate separately.

Product identification: Aein bei ke  E503806 (UL) Model number  *×**AWG(**mm²) temperature voltage  c(UL) Model number  *×**mm²(**AWG) temperature voltage    FT2
